Eddie Van Halen's guitar strings: the Frankenstrat and Wolfgang rig, sourced

Eddie Van Halen founded the band Van Halen in 1972 (as Mammoth, renamed in 1974) with his brother Alex Van Halen on drums, bassist Mark Stone, and singer David Lee Roth. Van Halen's 1978 self-titled debut redefined what rock guitar could sound like. The two-handed tap technique on Eruption, the harmonic-saturated rhythm tone, the use of a Floyd Rose locking tremolo for dive-bombs and squeals — every working rock guitarist after 1978 had to reckon with what Eddie Van Halen had done.

Twelve studio albums with Van Halen across 1978 to 2012 (David Lee Roth era, Sammy Hagar era, brief Gary Cherone era, Roth reunion era), plus the 1982 guest solo on Michael Jackson's Beat It that broadcast Eddie's voice to a pop audience without a single Van Halen reference. He invented or popularized the EVH Wolfgang signature guitar line, the Peavey 5150 amplifier, and the EVH 5150III amplifier. His 1977 hand-built Frankenstrat is held by the Smithsonian.

Eddie Van Halen passed away on October 6, 2020 from cancer at age 65. Van Halen the band did not continue after his passing. His son Wolfgang Van Halen has carried forward elements of his catalog and instruments through the Mammoth WVH project.

For most of his career, Eddie Van Halen played EVH Premium Electric Guitar Strings on the .009 to .042 set, the signature line he developed under Fender Musical Instruments after the EVH brand launched in 2007. Earlier in his career he had played Fender 150XL strings (.009, .011, .015, .024w, .032, .040), the gauge that sits on the Van Halen, Van Halen II, Women and Children First, and Fair Warning records. The EVH Premium .009-.042 set was designed to approximate those original 150XL gauges. Documented at the official Van Halen Store and Ground Guitar's deep-dive on the 150XL era.

His primary instrument from 1977 to 1983 was the Frankenstrat (also called Frankie), the custom-assembled Strat-style guitar with a single humbucker, Floyd Rose tremolo, and red-and-white striped paint. From 1996 forward he played the Wolfgang signature guitar, first produced with Peavey (1996 to 2004), then under his own EVH brand from 2007 onward. Both signature lines feature compact double-cut body, two custom humbuckers, Floyd Rose-style tremolo, and the fast neck Eddie had specified.

His amp progression moved through three eras. A modified Marshall Plexi Super Lead 100 in the 1970s and early 1980s, including the famous Variac trick of slightly under-volting the AC mains. Peavey 5150 from 1992, his first signature amp, used through For Unlawful Carnal Knowledge and the 1990s catalog. EVH 5150III from 2007 forward, his own brand's successor amp, used through A Different Kind of Truth (2012) and the rest of his career. Marshall's official Guitar Heroes feature documents the early-era relationship.

The "brown sound," Eddie's signature saturated tone, was not built from distortion pedals. It was built from a sequence of carefully chosen variables stacking to a single output. The Frankenstrat's single humbucker (a wound-by-hand pickup with no tone control bypass) had a focused mid-range hit. The Floyd Rose locking tremolo held tuning under his dive-bombs and squeals. The Variac running the Marshall Plexi at slightly under-spec voltage sagged the power supply, which softened the attack and added compression at the input stage. Push the volume hard, let the tubes saturate naturally, run the result into a sealed-back 4x12 cabinet.

Strings sat in this signal chain as a calibrated component. The .009 plain top string supported the wide vibrato and the long bend lines. The .024 wound G in the original 150XL set retained tone definition where modern .017 plain G strings can read brittle through saturation. The hand-balanced gauge progression from .009 plain to .040 wound low E carried equal output across the strings, which mattered for the two-handed tapping passages where any string-to-string output imbalance would expose itself.

When Eddie moved to the Peavey 5150 in 1992 and the EVH 5150III in 2007, the brown sound carried forward but with more immediate gain on tap. The Variac trick became less essential because the 5150 series was designed with the saturation built into the preamp voicing rather than the power-amp sag. Different amp, same conceptual destination: tubes pushed past clean, single humbucker focused into the gain stage, no pedals interrupting the signal.

Active endorsement relationships during Eddie's lifetime:

• Peavey: Wolfgang signature guitar 1996 to 2004, 5150 amplifier 1992 to 2004. Endorsement.

• EVH (Fender Musical Instruments): signature instruments, amps, strings, pedals, and accessories from 2007 to 2020. Endorsement. The EVH brand continues post-2020.

• Floyd Rose: Eddie was the most influential early adopter of the Floyd Rose double-locking tremolo, which became standard on his signature guitars. Verified use; not a formal endorsement deal.

• Marshall: the modified Plexi was Eddie's documented amp from the 1970s through the early 1980s. Marshall's official Guitar Heroes feature confirms the historical relationship; not a current endorsement.

Eddie's catalog and signature lines are framed in past tense throughout this page per the deceased-artist editorial posture; the EVH brand and the Fender-distributed signature instruments and strings continue in production.
